Platform scissor lift 5t ATH-Cross Lift 50

Description

Universal electro-hydraulic scissor lift for wheel alignment with a load capacity of 5 tons, ATH-Cross Lift 50 with a second level lift, floor or built-in lift installation

• High-precision manufacturing with laser cutting and robotic welding
• Reliable and less sensitive hydraulic drive, almost maintenance-free
• Suitable for floor or surface installation with optional drive-in ramp kit
• For passenger cars and long wheelbase vehicles
• The ideal camber lift; with recess for swivel plates at the front, pneumatically lockable sliding plates at the rear already installed and integrated central lift scissor (capacity of central lift scissor: 4000 kg, lift height: 450 mm)
• Can be used universally with flat platforms and rails for an optional roller jack.
• Hydraulic sequencing (master and slave cylinders) ensures uniform raising and lowering of the scissors; the built-in light barrier constantly monitors the synchronization of the lift
• Pneumatic slot release, emergency lowering system for lowering in case of power failure, CE stop and horn
• Push-button raised and lowered
• Pneumatic slot release, cable slack protection, emergency lowering system for descent in case of power failure, CE stop and horn
• Partially galvanized, double powder coated and platform protected with a special polymer
• Ideal lift for car repair, wheel, headlight and driver assistance system installation, car wheel alignment procedure
